- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com.au
- Brand Name
- Schneider Electric
- Product Line
- Easy UPS 3M
- Marketing Information
Easy-to-install, easy-to-connect, easy-to-use, and easy-to-service 120 kVA 3 phase UPS with advanced product features, robust electrical specifications and compact design making your business continuity easy. Ideal for small and medium data centers and other business critical applications, this UPS is EcoStruxure-ready to give you peace of mind with cloud-based remote monitoring and management. It is supplied without batteries, so you can easily customize your battery solution. Includes 5x8 start-up service.
- Packaged Quantity
- 1 Pack
- Product Type
- Double Conversion Online UPS
- Warranty
- Limited Warranty
- 1 Year
- Additional Warranty Information
1 year on-site repair or replace with factory authorized Start-Up
- Technical Information
- Phase
- Three Phase
- Application/Usage
- Business
- Data Center
- Business Critical Application
- Power Description
- Load Capacity (VA)
- 120 kVA
- Load Capacity (Watt)
- 120 kW
- Input Voltage
- 380 V AC
- 415 V AC
- Input Voltage Range
- 342 V - 477 V
- Output Voltage
- 380 V AC
- 400 V AC
- 415 V AC
- Input Frequency
- 70 Hz
- Output Frequency
- 60 Hz
- Waveform Type
- Sine Wave
- Input Power Factor
- 0.9
- Display & Graphics
- Display
- LED
- Interfaces/Ports
- USB
- Yes
- Environmental Conditions
- Maximum Operating Temperature
- 40°C
- Maximum Operating Elevation
- 1.50 km
- Maximum Storage Elevation
- 15.24 km
- Storage Relative Humidity
- 95%
- Sound Emission (A-Weighted)
- 72 dB(A)
- Thermal Dissipation
- 20473 BTU/h
- Physical Characteristics
- Product Color
- White
- Form Factor
- Tower
- Height
- 130 mm
- Width
- 50 mm
- Depth
- 82 mm
- Weight (Approximate)
- 193 kg
- Miscellaneous
- Package Contents
- Easy UPS 3M 120kVA Tower UPS
- Dust Filter
- Installation Guide
- Start-Up Service
- Environmentally Friendly
- Yes
- Environmental Compliance
- China Restriction of Hazardous Substances (China RoHS)
- Restriction of Hazardous Substances (RoHS)
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
